Example:
Creating a New Linked
Revit Discipline Model
Use the Imperial Multi-discipline Template
Structural
Mechanical
Plumbing
Electrical
Coodination
Link to the Existing Architectural Model
Link to Revit Cloud Model using
Auto - Project Base Point to Project Base Point
Acquire Coordinates from the Linked Model
Copy/Monitor Coordination Elements
Spatial Framework
Levels
Grids
Placement Elements
Structural Floors
Structural Walls
Create Additional Coordination Views as Needed
View Properties
Discipline
Structural
Architectural
Coordination
Visibility Graphics Overrides
Show
Curtain Walls
Curtain Panels
Curtain Mullions
Walls
Doors
Show/Hide Analytical Model
Cross-Link New Discipline Model
Back to Original Architectural Model
Link Revit Model
Auto - Project Base Point to Project Base Point
Adjust Views
Show Elements in Linked Model
Structural Columns
Structural Framing
