Biological Molecules Concept Map

Biological Molecules Concept Map

Biological Molecules Concept Map

Control Group

A group in the experiment where a variable is not being tested

Cytoskeleton

A network of protein filaments located within the cytoplasm of a cell

Golgi apparatus

An organelle which helps package protein and lipid molecules

Endoplasmic Reticulum

There are two different types; Smooth ER-do not have ribosomes attached Rough ER-has ribosomes attached
A combination of membranes within a cell which help with the movement of proteins and other molecules

Ribosome

The part in a cell responsible for making proteins

Vacuole

In animals: helps to store wanted substances and get rid of unwanted substances
In plants: helps maintain water balance

Lysosome

They break down the excess or "worn-down" parts of the cell
A membrane-enclosed organelle which contains the digestive enzymes

Cell Membrane

The phospholipid bilayer which acts as a barrier and protects the cell from unwanted materials/helps with the transport process of materials in and out of the cell

Nucleus

Important organelle of a cell
Membrane-enclosed organelle which contains the chromosomes

Chloroplasts

Where photosynthesis takes place
Contains chlorophyll
Found only in plant cells

Mitochondria

A membrane-bound organelle
The powerhouse of the cell which provides energy to the rest of the cell

X-Ray Crystallography

Subtopic
A method used to identify the different arrangements of atoms using a crystal

Electron Microscope

A scientific instrument used by projecting electrons in order to properly examine and magnify a microscopic specimen

Micrometer

A type of measurement used to measure the thickness or diameter of a microscopic object

Food System

Example the bunny eats the grass and the fox eats the bunny for energy
A web like structure explaining the process in which organisms are used and consumed

Heterotroph

Organisms that consume other organisms for energy and nutrients like humans

Autotroph

An organism that can produce its own food like plants through photosynthesis

Double Helix

The physical structure in DNA formed by two complimentary strands of nucleotides which are bonded together by hydrogen bonding and the nitrogenous bases connecting with their complimentary base

Potential Energy

The energy previously stored for use throughout the body

cAMP

A hydrophilic molecule used to transport messages throughout the cell

FAD

Accepts high energy electrons and carries them to the electron transport chain to help with the synthesizing of ATP molecules
Involved/used in cellular respiration

NADP+

Found naturally in the body and is used to regenerate energy for the body to use

NAD+

An electron carrier used to help temporarily store energy during cellular respiration

ATP

Source of energy used for storage and providing energy at the cellular level

Deoxyribose

A pentose sugar which is important in the making of DNA

Ribose

A simple sugar (carbohydrate)

Nitrogenous Base

There are purines: adenine and guanine and pyrimidines: thymine, cytosine and uracil
The nitrogenous bases in RNA are adenine, uracil, guanine, and cytosine Adenine pair with uracil and guanine pairs with cytosine
The nitrogenous bases in DNA are adenine, thymine, guanine, and cytosine Adenine pairs with thymine and guanine pairs with cytosine

Phosphodiester Bond

A chemical compound which contains an ester bond and a phosphate group

Nucleotide

Composed of 3 parts; the nitrogenous base, a pentose sugar and a phosphate group
Create the rungs of the ladder in DNA

Transmembrane Protein

A special type of integral protein
A protein which stretches across the whole width of a cell membrane

Glycoprotein

A molecule which contains a protein and a carbohydrate

Glycolipid

Lipids with a carbohydrate attached which are attached to the cell membrane

Controlled Variable

Something that is not changed throughout the whole experiment

Dependant Variable

A variable that relies on other variables

Independant Variable

The variable which is manupulted or changed during an experiment

Mosaic

Cells within the same organism have different genetic material

Bilayer

A double layer made up of molecules or atoms which are closely packed together like a phospholipid bilayer

Micelle

Particles formed by the combination and bonding of molecules that are water loving/hydrophilic and they create a "ball-shape"

Phosopholipid

A main part of the outer layer of an animal cell: the phospholipid bilayer containing 2 hydrophobic tails and a hydrophilic head

Ester Linkage

A bond formed between an alcohol and a carboxylic acid

Amphipathic

An example of an amphipathic structure is a phospholipid bilayer as it contains both a non-polar fatty acid tail and a polar head
A chemical structure containing both non-polar and polar segments

Steroid

A group of lipids with a specific chemical structure; a cyclical structure made up of rings of carbon atoms

Triglyceride

A type of lipid found in your blood made due to your body converting the calories you consume into these triglycerides

Glycerol

A colourless, odourless, and transparent liquid made from carbohydrates/the natural fermentation of sugars

Fatty Acid

The foundation of fats in our body and that we eat

Wax

A long chain of non-polar lipids

Hydrophilic

Example: The hydrophilic heads of a phospholipid bilayer
Parts of a molecule that mix well with water/is not afraid of water

Hydrophobic

Example:the hydrophobic fatty acid tails of a phospholipid bilayer
Parts of a molecule that do NOT mix with water/are afraid of water

Fair Test

A test where the independent variable is changed but the controlled variables are kept the same

Quaternary Structure

The combination of several protein chains/subunits

Tertiary Structure

The 3D structure/arrangement of the polypeptide chains in a protein

Secondary Structure

The H-Bonds create alpha-helix and beta-pleated sheets
Contain amino acid chains that are stabilized through hydrogen bonds from the proteins polypeptide backbone

Hormone

These messages are carried through your blood to your organs, skin, muscles, and every other type of tissue
They provide the coordination for different functions throughout the body
Chemical substances which act like messengers throughout the body

Neurotransmitter

They bind to neurotransmitter receptors which cause ion channels to open or close
A chemical messenger which allows neuron's to communicate with each other throughout the body

Receptor

A receptor is a molecule that is in or on a cell which will bind to a specific substance causing a specific effect to the cell

Polypeptide

A polypeptide is a chain of amino acids linked together

Peptide Bond

A peptide bond happens when the carboxyl group from an amino acid molecule is bonded with an amino group from another amino acid molecule

Side/R-Group

A chemical group that is attached/linked/bonded to the main part of the molecule called the chemical backbone

Amino Acid

Essential; your body does not make them and they need to be obtained from your diet Non-Essential; your body creates them naturally
There are 20 amino acids that your body needs; 9 essential and 11 non-essential
There are two different types of amino acids your body needs; essential and non-essential

Essential Amino Acid

There are 9 essential amino acids
Amino acids that can not be made by the body and need to be obtained from your diet

Macronutrient

There are 4 macronutrients; carbohydrates, proteins, lipids, and nucleic acids
Vitamins and minerals needed in small amounts for the body to do it's jobs properly

Polysaccharide

Similar to a oligosaccharide where it is a long chain of small carbohydrate molecules (monosaccharides) linked together

Oligosaccharide

Carbohydrates with two or more monosaccharides bonded together

Disaccharide

Formed when two simple sugars also known as monosaccharides combine together creating a more complex sugar through glycosidic linkages

Polymer

An example of a polymer is cellulose
Created due to the bonding and combining of monomers

Monomer

Small molecules that bond together to make a more complex group of molecules also known as a polymer

Glycosidic Linkage

A type of linkage which bonds a carbohydrate molecule to another group

Isomer

Two or more molecular compounds that have the same chemical formula but a different arrangement of atoms

Monosaccharide

the simplest version of both carbohydrate and sugar

Carbohydrate

A macronutrient and is a sugar molecule

Essential Nutrient

These nutrients are obtained from the foods you eat, your body does not make them on its own
There are 6 essential nutrients; vitamins, minerals, carbohydrates, fats, proteins and water

Hydrogen Bond

A specific type of dipole-dipole bonding between molecules

Intermolecular Forces of Attraction

The forces between molecules

Polarity

Non-Polar molecules: the atoms have the same charge/the charge is distributed across the molecule evenly
Polar molecules: the atoms have opposite charges/the charge is not distributed across the molecule evenly
The relationship between two molecules bonds

Functional Group

A specific group of atoms that provide specific characteristics for the molecule in which they are attached to
